Milling Head Options

All milling heads include 35˚, 90˚ head, extension head and universal head are self developed and assembled.

The contact surface of all milling heads and covers are precisely hand scraped while using the Japanese 2-piece curvic coupling for precision positioning.

The automatic milling head can be controlled by programming.

Optional Milling Head ( Manual )

35° Head

Manual head clamp / tool clamp
Manual 45° indexing
Max. speed : 3,000 rpm
Max. output : 22 kW ( 30 HP )

90° Head

Manual head clamp / tool clamp
Manual 45° indexing
Max. speed : 3,000 rpm
Max. output : 22 kW ( 30 HP )

Extension Head

Manual head clamp / automatic tool clamp
No index function
Max. speed : 3,000 rpm
Max. output : 22 kW ( 30 HP )

Universal Head

Manual head clamp / tool clamp
C-axis manual 45° indexing
A-axis manual 5° indexing
Max. speed : 3,000 rpm
Max. output : 22 kW ( 30 HP )

Optional Milling Head ( Semi-automatic )

Universal Head

Automatic head clamp / manual tool clamp
C-axis auto. 5° indexing
A-axis manual 5° indexing
Max. speed : 2,000 rpm
Max. output : 22 kW ( 30 HP )

Optional Milling Head ( Automatic )

35° Head

Automatic head & tool clamping
C-axis automatic 5° / 2.5° / 1° indexing
Max. speed : 3,000 rpm / 4,500 rpm
Max. output : Same as spindle output
Optional CTS

90° Head

Automatic head & tool clamping
C-axis automatic 5° / 2.5° / 1° indexing
Max. speed : 3,000 rpm / 4,500 rpm
Max. output : Same as spindle output
Optional CTS

Extension Head

Automatic head & tool clamping
Max. speed : 3,000 rpm / 6,000 rpm
Max. output : Same as spindle output
Optional CTS
